- Sturdy mechanical structure manufactured as per IS 2062 Grade.
- Reliable mounting assembly for load cells.
- Law resistance cables and weather proof junction box.
- Windows based friendly Software.
- Hermatically sealed load cells eliminates water logging.
- Accuracy 0. 02%.
- Each weighbridge is fully assembled at factory and performance tested Prior to delivery.
- Accurate “Weight” first time and every time.
- Faster installation than conventional systems.
- Software is password protected.
- Suitable for places having limited space. e. g. non hilly area.
- No ramps are required on either side.
- Most suitable for public weighbridges.
- Easy maintenance as platform is completely flushed to ground level.
- Designed carefully to withstand heavy loads without damage.
- Suitable for installation on surface which saves 60% cost of civil construction.
- Easy Installation & maintenance as all parts are accessible above ground level and therefore a profitable investment.
- Designed to install on hard rock area where pit excavation is not possible for more than three feet.
- Absence of moving parts and therefore little maintenance.
- Avoids accumulation of dust, soil and water. Also used where water logging is problem and where gases are present in the atmosphere.
- Easy cleaning with water hose pipe or compressor.
- Maintenance from inside the pit, pit lights and sump is not required.
- Structure is Installed on ground and have joists on the sides.
|Size of Platform||7.5 m x 3 m, 9 m x 3 m, 12 m x 3 m, 15 m x 3 m, 16 m x 3 m, 18 m x 3 m,|
|Capacity (tons)||30, 40, 50, 60, 80, 100, 120, 150, 200.|
|Interval(Kg)||5, 10, 20.|
|Type of Load cell||Double Ended Shear beam / Compression with IP 68 Protection.|
|Accuracy||As per OIML R-76. Class-III-Medium.|
|Non Linerity & Repeatability||0.05%.|
|Type of Platform||Steel based.|
|Cable used||4 Core shielded with SS Armor protection.|
|Out Door display||25-100 mm Seven Segment RED LED.|
|Temperature||Indicator : -10’c to+40’c / Platform : -30’c to+65’c|
|Power Supply||220v 50Hz to 230v 60Hz OR 110v 60Hz|
